Vector tiles provide performant rendering of map data for large vector feature datasets across large regions and zoom levels. Here’s why, and when, they should be used:
  • Vector tiles are designed for use in web maps, mobile apps, and desktop GIS software.
  • WherobotsDB makes it easy and affordable to generate vector tiles at a planetary scale.
  • By rendering vector tiles directly, the interactive map experience is more responsive and scalable for large datasets than rendering feature formats (e.g., GeoJSON) directly and allows developers to customize the display, which is otherwise impossible with raster tiles.
In this tutorial, we will create PMTiles vector tiles for rendering maps using building and road data from the Overture Maps Dataset. This dataset is located in the wherobots_open_data section of the Wherobots Cloud Spatial Catalog.

​
Start a WBC Notebook

Follow these instructions to open a notebook in Wherobots Cloud. Once a notebook is started you can open the tile_generation_example notebook located in notebooks_examples/python or notebooks_examples/scala in Jupyter lab, or create a new notebook tab in Jupyter lab and select the desired kernel (Python or Scala) to follow this tutorial.

​
Start a SedonaContext

As always, begin by starting a Sedona context
  • Python
  • Scala
from sedona.spark import *

config = SedonaContext.builder().getOrCreate()
sedona = SedonaContext.create(config)

​
Load Feature Data

Create a Spatial DataFrame with a geometry column and a layer column. The geometry column contains the features to render in the map. The layer column is a string that describes the grouping the feature should be in. Records within the same layer can be styled together, independently of other layers. In this case example features that represent buildings are in the buildings layer and those representing roads are in the roads layer. The first cell that follows gives some variable to control where we generate tiles. The default is a small town in Washington: Issaquah.
  • Python
  • Scala
from sedona.spark import *
import pyspark.sql.functions as f

# Set to False to generate tiles for the entire dataset, True to generate only for region_wkt area
filter = True
region_wkt = "POLYGON ((-122.097931 47.538528, -122.048836 47.566566, -121.981888 47.510012, -122.057076 47.506302, -122.097931 47.538528))"
filter_expression = ST_Intersects(f.col("geometry"), ST_GeomFromText(f.lit(region_wkt)))
Next, we create the buildings Spatial DataFrame using the Overture buildings table from the Wherobots Open Data Catalog (wherobots_open_data).
  • Python
  • Scala
buildings_df = (
  sedona.table("wherobots_open_data.overture_maps_foundation.buildings_building")
  .select(
    f.col("geometry"),
    f.lit("buildings").alias("layer"),
    f.element_at(f.col("sources"), 1).dataset.alias("source")
  )
)

buildings_df.show()
Next, we create a Spatial DataFrame for our road features using the Overture transportation segment table.
  • Python
  • Scala
roads_df = (
  sedona.table("wherobots_open_data.overture_maps_foundation.transportation_segment")
  .select(
    f.col("geometry"),
    f.lit("roads").alias("layer"),
    f.element_at(f.col("sources"), 1).dataset.alias("source")
  )
)

roads_df.show()
Next, we prepare a single spatial DataFrame combining our roads and buildings features.
  • Python
  • Scala
features_df = roads_df.union(buildings_df)

if filter:
    features_df = features_df.filter(ST_Intersects(f.col("geometry"), ST_GeomFromText(f.lit(region_wkt))))

features_df.count()

​
Create Tiles as a PMTiles Archive

Once we have the Spatial DataFrame ready for tile generation, we can use the vtiles.generate_pmtiles method to create a PMTiles archive. PMTiles is a performant, simple, and optimized format for storing vector tiles. Wherobots will automatically handle the details for you. However, if you need more control, a GenerationConfig object can optionally be provided as an argument to control which tiles are created and their contents. A PMTilesConfig object can optionally be provided to control the header information of the PMTiles Archive.
  • Python
  • Scala
from wherobots import vtiles
import os

full_tiles_path = os.getenv("USER_S3_PATH") + "tiles.pmtiles"
vtiles.generate_pmtiles(features_df, full_tiles_path)

​
Visualizing Vector Tiles with leafmap

We’ve made it easy to use leafmap to visualize the vector tiles we just generated. Leafmap is a popular geospatial visualization tool for Jupyter notebooks.
Visualization is only available in Python.
We offer a function that makes it easy to use leafmap. This function creates a signed URL, styles the tiles, and returns a Leafmap object. The function can be used as follows:
  • Python
vtiles.show_pmtiles(full_tiles_path)
If you are not using the Wherobots provided bucket to store tiles, ensure CORS is enabled on the bucket. Learn how to configure this in the CORS documentation.
Here is an example visualizing the PMTiles we developed. Purple areas are road layers and green areas are building layers. Leafmap

​
Quick Generation of Tiles

Sometimes you want to quickly visualize a massive dataset. To achieve this goal, WherobotsDB provides a function for quickly generating, saving, and displaying tiles. This feature can be used as follows:
  • Python
  • Scala
sample_tiles_path = os.getenv("USER_S3_PATH") + "sampleTiles.pmtiles"
vtiles.generate_quick_pmtiles(features_df, sample_tiles_path)
As a comprehensive map application toolbox, WherobotsDB provides many off-the-shelf scalable tools. In this tutorial, we just focus on a minimum example. Detailed explanation of each tool can be found at References.
